* Hotel lock approved by EN 12209 and EN179 | |||||||||
* Handy | |||||||||
* Distance between center to center: 72 or 85 mm | |||||||||
* Backset distances 55,60 and 65 mm | |||||||||
* Panic function retracted the deadbolt from inside | |||||||||
* Stainless steel silent latch, dead bolt and 2pcs follower SUS 304 | |||||||||
* Faceplate round or square, 20 or 24 mm | |||||||||
* Crossing holes for the rose | |||||||||
* 15 mm long cam profile cylinder, with three keys | |||||||||
* Stainless steel strike | |||||||||
* Without rose | |||||||||
* Deduct €1,50 if the cylinder is not required | |||||||||
* Deduct €0,60 if the strike is not required |
reference | function | finish | backset | turns | follower | ||||||||
E9517-55 | Hotel | S. S. | 55 | 1 | 8 | ||||||||
E9517-60 | Hotel | S. S. | 60 | 1 | 8 | ||||||||
E9517-65 | Hotel | S. S. | 65 | 1 | 8 |
